Automatic battery pulse charger 12V
Automatic battery chargers with program for charge conservation (pulse recharge).
Suitable for charging lead batteries: WET serviceable and maintenance free, AGM, AGM Power, GEL, Start & Stop.
Multi step charging: the batteries are charged by applying sophisticated multi-step programs.
High efficency: "I-U" Charging characteristic (constant current - constant voltage) minimises battery charging time.
Maintenance Function "Pulse Maintenance": can remain connected to the battery for a long time. Keeps the battery ready for use through the pulse charge.
Safety guaranteed: designed to protect vehicle electronics. Non-sparking. Reverse polarity protected and short-circuit proof.
IP65
Lightweight and compact battery charger.
Built for outdoor use.
8 Steps charging program.
Battery, starter and alternator tester
5 different operation modes
Normal Charging: 7,0 Amp - 14,4 Volt >>> 7,0 Amp - 14,7*Volt
*Cold weather and AGM Power batteries
Battery "Equalization" function can be added to all charging programs (Reconditioning: 1,5Amp 16,0 Volt).
DC Power supply (7 Amp 13,6Volt). Starting the charge of batteries having to low charge / "Back-up".
Parameters
Protection degree (IP) | IP65 |
Battery capacity | 14 - 150 Ah |
Power supply | 230/1 V/fāze |
Sizes | 202 x 90 x 45 mm |
Power | 0,12 kW |
Nominal battery voltage | 12 V |
Number of programs | 5 Gab |
Weight | 0,65 kg |
Average charging current | 7 A |
