Elektrohidrauliskais 4-statņu autopacēlājs 6500kg
Equipment which integrates inspection, maintenance, and wheel aligment functions as one integral, with aesthetic design.
Drived by hydraulic cylinders and transmitted by steel cables, the working environment is quiet.
Equipped with pneumatic safety lock, which can be locked at any required height to operate, safe and reliable.
The level of the runway plate in the locked position can be adjusted to meet the needs of precise inspection, reparation and parking.
Common type machine only for the inspection and repair purposes.
Used for wheel alignment. Equipped with 2 sets of sliding plates and a secondary lifting.Optional with turntables.
Parametrai
Atstatums starp platformām | 1078 - 1178 mm |
Celtspēja | 6500 kg |
Elektrobarošana | 380V/50Hz V/fāze |
Motora jauda | 3.0 kW |
Pacelšanas augstums | 241-1941 mm |
Platformas garums | 5769 mm |
Platformu platums | 508 mm |
Šķērsdomkrata pacelšanas augstums | 330 mm |
