Divstatņu pacēlājs bez atbalsta rāmja
- Symmetric lift without baseframe for greater space free area at work. The connecting cables can be fixed to the ceiling or recessed into the floor
- Electronic synchronisation between carriages to keep the height difference within a max of 24 mm
- Two specially manufactured high performing motors to provide long life; fitted with protecting thermic sensor
- Low voltage controls
- Designed with 4 extended three-stage arms: ideal for lifting vans and long wheel based vehicles, whilst perfect for standard vehicles
- Pads min. height 103 mm only for the asymmetric lifting of big cars in armoured version
- Permanent and automatic screw lubrication
- Operation: electro-mechanical
Параметры
Грузоподъемность | 4000 kg |
источник питания | 230-400V/50 Hz |
Макс. высота | 1900 mm |
Мощность мотора | 2 x 2,6 kW |
Время подъема | 55 s |
Bес | 700 kg |
