Electro-mechanical asymmetric lift with chain drive
- Lift with self supporting baseframe for easier installation on poor quality floor surfaces
- Pads with a min. height of 90 mm only. Three stage short and long arms enabling the asymmetric loading of wide and longer vehicles: recommended for the lifting of off-road vehicles
- High resistance chain transmission, pre-stretched, with control safety device upon looseness
- Permanent and automatic screw lubrication
- Specially manufactured high performing motor fitted with overheating & overload protection switch
- Operation: electro-mechanical
Parameters
Capacity | 3200 kg |
Power supply | 230-400V/50 Hz |
Max. height | 1890 mm |
Motor power | 4,5 kW |
Lifting time | 55 s |
Weight | 700 kg |
