Gift ideasElectro-mechanical mobile column lifts RAV232NL
Screws are automatically lubricated by felt pads feeded by an oil tank which guarantees lubrication during movement. A series of Ertalon runners (10 per carriage), with low friction coefficient and excellent resistance to wear, guarantee balanced lifting of the vehicle in any position.
Simultaneous operation of all columns. Electronic system ensuring synchronization of all columns. Safety stop in case of malfunction. Electronic device checks the correct main supply phase sequence. Low voltage controls (24 V) on the main column with dead-man push buttons
Electronic system ensuring synchronization of all columns (PLC programmable controller with self-diagnostic system). Safety stop in case of malfunction. Possibility to select several operating modes: - simultaneous operation of all columns. - one or more pairs of columns. - single column. Electronic device selects automatically the correct main supply phase sequence. Low voltage controls (24V) on all columns with deadman push buttons and safety interlock in case of interference in the activated control
Control panel of the main column featuring all controls.
Secondary control panel, featuring lifting and lowering controls and emergency stop button.
Parameters
| Capacity | 4x5.5 kg |
| Rim diameter | 22.5 " |
| Max. wheel diameter | 1200 mm |
| Motor power | 4x3.5 kW |
| Lifting time | 120 s |
