Hydraulic bottle jack with double lift telescopic rams for extra long stroke 10t
- Model with spindle extension offer optimum use of the stroke
- Model with bevelled base (see table) offer increased stability and safety as the jack follows the tilt of the vehicle when lifting
- 3 part galvanised pump handle for easy storage
- Built-in safety overload valve
Parameters
Capacity | 10000 kg |
cylinder movement | 260 mm |
Max. height | 530 mm |
Min. height | 200 mm |
Screw extension | 85 mm |
Weight | 10,2 kg |
