Features
CENTER POST CLAMPING SYSTEM
- Easy and precise locking system
- Completely mechanical, easy maintenance
SIDE LIFT
- Lifting capacity up to 80 kg
- It allows to work always in an ergonomic position
- It increases productivity
ERGONOMIC AND ADJUSTABLE CONSOLE
- Adjustable control console: ergonomic
- Intuitive sequence of operations
- Integrated manometer
- Release buttons on side
- Tested for long life use
BEAD BREAKER DISKS / ARMS
- Double arms bead breakers system
- Dual synchronized, simultaneous movements
- Shape structure designed to fit the wheel profile
- Tilting structure to avoid wheel damages
- Mechanical locking system for an “easy-memory”
- Easy side disengage for fast release
S-Talon
- Patented mounting & dismounting tool
- Bead stress minimization thanks to its swinging movement
- Intuitive hooking
- No touch
- Double tool for mounting & dismounting operations
AUXILIARY MOUNTING TOOL
- Auxiliary tools for an easy insertion of the bead
- Manual & fast setup
- Plastic protection to avoid damages
- Optional and user-friendly application
Scope of Delivery
- 1 x Cones protection
- 1 x locking system pin protection
- 3 x Cones
- 1 x Locking nut + Shaft
- 1 x Flange reverse wheel adaptor + rubber protection
- 1 x Brush
- 1 x Plastic Level
Parameters
Rim diameter | 13″ – 32 " |
Power supply | 230/1 V/fāze |
Air pressure | 8 - 10 bar |
Sizes | 1790 x 1100 x 1630 mm |
Max.wheel diameter | 1200 mm |
Bead Breaker Force | 5000N kg |
wheel width | 16 " |
Speed of rotation | 7 - 18 (2 ātrumi) apgr/min |
Weight | 470 kg |
