Wheel balancer with LCD screen and laser measuring arm
2451 L is a wheel balancer with laser measuring arm entering wheel parameters and wheel guidance system directing the wheel to unbalance point. The system memorizes the data and shows precisely the weight position. The machine is equipped with ultrasonic sonar for contactless wheel width measurement and rim recognition system according to the entered parameters.
The completely new operating system based on two buttons and a wheel as a selection cursor makes the machine very intuitive to use.
Automatic positioning lock
Laser measuring arm
Ultrasonic non-contact rim width acquisition
Voice synthesizer
ALU programmes
2 ALU programmes for motorbikes
programme "hidden weight"
optimization
LCD monitor
Parameters
| Balancing speed | 140 apgr/min |
| Balancing accuracy | 1g |
| Rim diameter | 10"-30" |
| Rim width | 2"-15" |
| Power supply | 230V/50Hz |
| Sizes | 1000x1170x1450mm |
| Motor power | 80W |
| wheel weight | 70kg |
| Weight | 120kg |
