Gift ideasElectric 2-speed winch 12V 5443kg
- Free spooling clutch
- Runva patent three stage planetary gear reducer
- Two speed and clutch and speed shift structure
- Runva patent three stage planetary gear reducer
- Clutch and two speed gear actions auto engagement
- Automatic screw cone braking action
- Series wound motor
- Wireless remote control available
- Remote control through control box and switch
- DC 12v or DC 24v Power drive optional
Parameters
| Power supply | 12 V/fāze |
| Gear reduction ratio | 267:1 (1.ātrums) / 86:1 (2.ātrums) |
| Weight | 44 kg |
| Wire rope diameter | 10.2 mm |
| Wire rope length | 25.5 m |
| Line Speed | 1.5/3.2 (1./2.ātrums) m/min |
| Pulling capacity | 5443 t |
